OEM#: 6024-2NSC3New OEM Original Outright
RADIAL BALL BEARING 6024-2RS, DOUBLE SEALED, 120MM BORE, 180MM OD by Nachi America Inc
Your price:
$405.83 each
OEM#: 6024-2NSC3RADIAL BALL BEARING 6024-2RS, DOUBLE SEALED, 120MM BORE, 180MM OD by Nachi America Inc
New OEM Original Outright
Your price:
$405.83 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
NACHI Radial Ball Bearing 6024-2RS, Double Sealed, 120MM Bore, 180MM OD
Radial Ball Bearing has moderate load-carrying capacity in both radial and axial directions and is good for high speed and high accuracy. Rubber seal or metal shield on one or both sides of the bearing helps keep out dirt and contaminants. In case two seals or two shields are used, the bearing is lubricated by grease for its life when manufactured. The bearing with 10 to 75 mm bore (6000 to 6300 series) & 10 to 50 (6800 & 6900 series) improves reliability with newly designed seal and shield, and suitable grease. Quiet rotation is expected by improved accuracy of components, and saving cost and energy is also expected by lower power loss provided by low and stable running torque.
Radial Ball Bearing has moderate load-carrying capacity in both radial and axial directions and is good for high speed and high accuracy. Rubber seal or metal shield on one or both sides of the bearing helps keep out dirt and contaminants. In case two seals or two shields are used, the bearing is lubricated by grease for its life when manufactured. The bearing with 10 to 75 mm bore (6000 to 6300 series) & 10 to 50 (6800 & 6900 series) improves reliability with newly designed seal and shield, and suitable grease. Quiet rotation is expected by improved accuracy of components, and saving cost and energy is also expected by lower power loss provided by low and stable running torque.
Technical Specs
P/N: 6024-2NSC3 Key Specs
Item
RADIAL BALL BEARING 6024-2RS, DOUBLE SEALED, 120MM BORE, 180MM OD
OEM
Nachi America Inc
OEM #
6024-2NSC3
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Type
Double Sealed
Bore (Mm)
120
Country of Origin
Japan
Dynamic Load Rating (N)
88,000
Max Speed / Grease (Rpm)
2,100
Od (Mm)
180
Radial Clearance
C3
Series
6000
Static Load Rating (N)
79,500
Tolerance
ISO Class 0
Width Millimeters
28
NACHI Radial Ball Bearing 6024-2RS, Double Sealed, 120MM Bore, 180MM OD
Radial Ball Bearing has moderate load-carrying capacity in both radial and axial directions and is good for high speed and high accuracy. Rubber seal or metal shield on one or both sides of the bearing helps keep out dirt and contaminants. In case two seals or two shields are used, the bearing is lubricated by grease for its life when manufactured. The bearing with 10 to 75 mm bore (6000 to 6300 series) & 10 to 50 (6800 & 6900 series) improves reliability with newly designed seal and shield, and suitable grease. Quiet rotation is expected by improved accuracy of components, and saving cost and energy is also expected by lower power loss provided by low and stable running torque.
Radial Ball Bearing has moderate load-carrying capacity in both radial and axial directions and is good for high speed and high accuracy. Rubber seal or metal shield on one or both sides of the bearing helps keep out dirt and contaminants. In case two seals or two shields are used, the bearing is lubricated by grease for its life when manufactured. The bearing with 10 to 75 mm bore (6000 to 6300 series) & 10 to 50 (6800 & 6900 series) improves reliability with newly designed seal and shield, and suitable grease. Quiet rotation is expected by improved accuracy of components, and saving cost and energy is also expected by lower power loss provided by low and stable running torque.
