OEM#: GT1027New OEM Original Outright
EPACT EFFICIENCY MOTOR, 25HP, 3600RPM, 230/460V, 3PH, 284TS FR, TEFC by Marathon Motors
Your price:
$2,916.06 each
OEM#: GT1027EPACT EFFICIENCY MOTOR, 25HP, 3600RPM, 230/460V, 3PH, 284TS FR, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$2,916.06 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors EPAct Efficiency Motor, GT1027, 25HP, 3600RPM, 230/460V, 3PH, 284TS FR, TEFC
Marathon's EPAct Efficient Motors are designed meet the new Energy Efficient standards. These Motors are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction. Horsepower ranges from 1/3 - 400 Hp.
Marathon's EPAct Efficient Motors are designed meet the new Energy Efficient standards. These Motors are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction. Horsepower ranges from 1/3 - 400 Hp.
Technical Specs
P/N: GT1027 Key Specs
Item
EPACT EFFICIENCY MOTOR, 25HP, 3600RPM, 230/460V, 3PH, 284TS FR, TEFC
OEM
Marathon Motors
OEM #
GT1027
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
50 Hertz Fl Amps
55/27.5
50 Hertz Fl Eff
91.70 Percent
50 Hertz Hp
20
50 Hertz Kw
14.9
50 Hertz Rpm
3000
50 Hertz Sf
1.15
50 Hertz Voltage
190/380
60 Hertz Kw
18.7
Ambient Temp C
40
Approval-Ce
Y
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
6211
Bearing-Opp-Drive-End
6211
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6211
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
56/28
Fl Efficiency
91.7
Frame
284TS
Horsepower
25
Insulation Class
F
Ip Code
43
Is_Motor
Yes
Kva-Code
G
Model Number
284TSTFCA6001
Motor Rpm 60Hz
3600
Mounting
Rigid
Nameplate Rpm
3600
Nema Design
B
Opposite End Bearing Size
6211
Orientation
Horizontal
Phase
3
Rpm Range
3001-3600
Service Factor
1.15
Starting Type
Across The Line
Ul
Recognized Construction
Voltage
230/460
Weight
510
